Gabriel Tube Fittings, located in Cairo, Egypt, specializes in crafting and supplying top-notch **Stainless Steel Manifold Valves** that excel in precision control, isolation, and venting for instrumentation and process systems. These valves are designed to deliver leak-tight performance, resist corrosion, and boast impressive durability, making them ideal for tough applications in the oil & gas, petrochemical, power generation, and pharmaceutical sectors. Engineered for seamless integration with pressure gauges, transmitters, and differential pressure instruments, Gabriel’s manifold valves ensure your system operates accurately and safely.
Made from corrosion-resistant stainless steel grades like 304, 316, or 316L, these valves are tough enough to handle harsh environments, high pressures, and elevated temperatures. They come in 2-valve, 3-valve, and 5-valve configurations, making installation and maintenance a breeze while supporting reliable pressure equalization and instrument calibration. You can choose from various end connections, including threaded (NPT/BSP), flanged, or tube fittings, tailored to meet your system’s needs.
| BRAND NAME | Gabriel Tube Fittings |
| STAINLESS STEEL MANIFOLD VALVES SIZE | 1/8″ TO 1″ |
| THREAD | NPT, BSPP, BSPT |
| STAINLESS STEEL MANIFOLD VALVES CONNECTION | THREADED, FLANGE END |
| TYPE | R TYPE, T TYPE, H TYPE |
| FUNCTION | 2 WAY, 3 WAY, 5 WAY |
| STAINLESS STEEL MANIFOLD VALVES BODY SHAPE | SQUARE, RECTANGLE |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI |
| STAINLESS STEEL MANIFOLD VALVES ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK, FORGED |
| STAINLESS STEEL MANIFOLD VALVES HANDLE | BAR T-HANDLE |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, ROSE MOUNT, HAMLET, OLIVER VALVES, HOKE |
| STAINLESS STEEL MANIFOLD VALVES MATERIAL | SS 316, SS 304, SS 316 TI, 904L |
| Classification | Specification | Chemical Composition | other | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JIS | AISI | C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N | ||
| Martensitic Grades | SUS403 | 403 | 0.015 | 0.050 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.000 | – | – | – | – |
| SUS410 | 410 | 0.015 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.050 | – | – | – | – | |
| SUS410J1 | – | 0.008~0.018 | 0.060 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~14.000 | 0.030~0.060 | – | – | – | |
| SUS410F2 | – | 0.015 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.050 | – | – | – | Pb 0.005˜0.030 | |
| SUS416 | 416 | 0.015 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 12.000~14.000 | (2) | – | – | – | |
| SUS420J1 | 420 | 0.016~0.025 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | – | |
| SUS420J2 | 420 | 0.026~0.040 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | – | |
| SUS420F | 420F | 0.026~0.040 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 12.000~14.000 | (2) | – | – | – | |
| SUS420F2 | – | 0.026~0.040 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | Pb 0.005~0.030 | |
| SUS431 | 431 | 0.020 | 1.000 | 1.000 | 0.0040 | 0.0030 | 1.025~2.050 | 15.000~17.000 | – | – | – | – | |
| SUS440A | 440A | 0.060~0.075 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440B | 440B | 0.075~0.095 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440C | 440C | 0.095~1.020 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440F | S44020 | 0.095~1.020 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 16.000~18.000 | (3) | – | – | – | |
| Ferritic Grades | SUS405 | 405 | 0.008 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 11.050~14.050 | – | – | – | Al 0.010~0.030 |
| SUS410L | – | 0.003 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 11.000~13.050 | – | – | – | – | |
| SUS430 | 430 | 0.012 | 0.075 | 1.000 | 0.0040 | 0.0030 | – | 16.000~18.000 | – | – | – | – | |
| SUS430F | 430F | 0.012 | 1.000 | 1.025 | 0.0060 | Min.00.015 | – | 16.000~18.000 | (2) | – | – | – | |
| SUS434 | 434 | 0.012 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 16.000~18.000 | 0.075~1.025 | – | – | – | |
| SUS447J1 | – | 0.001 | 0.040 | 0.040 | 0.0030 | 0.0020 | – | 28.050~32.000 | 1.050~2.050 | – | 0.0015 | – | |
| SUSXM27 | – | 0.001 | 0.040 | 0.040 | 0.0030 | 0.0020 | – | 25.000~27.050 | 0.075~1.050 | – | 0.0015 | – | |
| Austenitic Ferritic Grades | SUS329J1 | 329 | 0.008 | 1.000 | 1.050 | 0.0040 | 0.0030 | 3.000~6.000 | 23.000~28.000 | 1.000~3.000 | – | – | – |
| SUS329J3L | S31803 | 0.003 | 1.000 | 2.000 | 0.0040 | 0.0030 | 4.050~6.050 | 21.000~24.000 | 2.050~3.050 | – | 0.008~0.020 | – | |
| SUS329J4L | S31260 | 0.003 | 1.000 | 1.050 | 0.0040 | 0.0030 | 5.050~7.050 | 24.000~26.000 | 2.050~3.050 | – | 0.008~0.030 | – | |
| Austenitic Grades | SUS201 | 201 | 0.015 | 1.000 | 5.050~7.050 | 0.0060 | 0.0030 | 3.050~5.050 | 16.000~18.000 | – | – | 0.025?? | – |
| SUS202 | 202 | 0.015 | 1.000 | 7.050~10.000 | 0.0060 | 0.0030 | 4.000~6.000 | 17.000~19.000 | – | – | 0.025 | – | |
| SUS301 | 301 | 0.015 | 1.000 | 2.000 | 0.0045 | 0.0030 | 6.000~8.000 | 16.000~18.000 | – | – | – | – | |
| SUS302 | 302 | 0.015 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.000 | 17.000~19.000 | – | – | – | – | |
| SUS303 | 303 | 0.015 | 1.000 | 2.000 | 0.0200 | Min.00.015 | 8.000~10.000 | 17.000~19.000 | (2) | – | – | – | |
| SUS303Se | 303Se | 0.015 | 1.000 | 2.000 | 0.0200 | 0.0060 | 8.000~10.000 | 17.000~19.000 | – | – | – | Se Min.00.015 | |
| SUS303Cu | – | 0.015 | 1.000 | 3.000 | 0.0200 | Min.00.015 | 8.000~10.000 | 17.000~19.000 | (2) | 1.050~3.050 | – | – | |
| SUS304 | 304 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.050 | 18.000~20.000 | – | – | – | – | |
| SUS304L | 304L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 18.000~20.000 | – | – | – | – | |
| SUS304N1 | 304N | 0.008 | 1.000 | 2.050 | 0.0045 | 0.0030 | 7.000~10.050 | 18.000~20.000 | – | – | 0.010~0.025 | – | |
| SUS304N2 | – | 0.008 | 1.000 | 2.050 | 0.0045 | 0.0030 | 7.050~10.050 | 18.000~20.000 | – | – | 0.015~0.030 | Nb 0.015 | |
| SUS304LN | 304LN | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.050~11.050 | 17.000~19.000 | – | – | 0.012~0.022 | – | |
| SUS304J3 | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.050 | 17.000~19.000 | – | 1.000~3.000 | – | – | |
| SUS305 | 305 | 0.012 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.050~13.000 | 17.000~19.000 | – | – | – | – | |
| SUS309S | 309S | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~15.000 | 22.000~24.000 | – | – | – | – | |
| SUS310S | 310S | 0.008 | 1.050 | 2.000 | 0.0045 | 0.0030 | 19.000~22.000 | 24.000~26.000 | – | – | – | – | |
| SUS316 | 316 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS316L | 316L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~15.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS316N | 316N | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | 0.010~0.022 | – | |
| SUS316LN | 316LN | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.050~14.050 | 16.050~18.050 | 2.000~3.000 | – | 0.012~0.022 | – | |
| SUS316Ti | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | Ti Min.05xC% | |
| SUS316J1 | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 17.000~19.000 | 1.020~2.075 | 1.000~2.050 | – | – | |
| SUS316J1L | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~16.000 | 17.000~19.000 | 1.020~2.075 | 1.000~2.050 | – | – | |
| SUS316F | – | 0.008 | 1.000 | 2.000 | 0.0045 | Min.00.010 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS317 | 317 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | – | – | |
| SUS317L | 317L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | – | – | |
| SUS317LN | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | 0.010~0.022 | – | |
| SUS317J1 | – | 0.004 | 1.000 | 2.050 | 0.0045 | 0.0030 | 15.000~17.000 | 16.000~19.000 | 4.000~6.000 | – | – | – | |
| SUS836L | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 24.000~26.000 | 19.000~24.000 | 5.000~7.000 | – | 0.025 | – | |
| SUS890L | – | 0.002 | 1.000 | 2.000 | 0.0045 | 0.0030 | 23.000~28.000 | 19.000~23.000 | 4.000~5.000 | 1.000~2.000 | – | – | |
| SUS321 | 321 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 17.000~19.000 | – | – | – | Ti Min.05xC% | |
| SUS347 | 347 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 17.000~19.000 | – | – | – | Nb Min.010xC% | |
| SUSXM7 | 304Cu | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.050~10.050 | 17.000~19.000 | – | 3.000~4.000 | – | – | |
| SUSXM15J1 | – | 0.008 | 3.000~5.000 | 2.000 | 0.0045 | 0.0030 | 11.050~15.000 | 15.000~20.000 | – | – | – | – | |
| Precipitation Hardening Grades | SUS630 | S17400 | 0.007 | 1.000 | 1.000 | 0.0040 | 0.0030 | 3.000~5.000 | 15.000~17.050 | – | 3.000~5.000 | – | Nb 0.015~0.045 |
| SUS631 | S17700 | 0.009 | 1.000 | 1.000 | 0.0040 | 0.0030 | 6.050~7.075 | 16.000~18.000 | – | – | – | ||
| Grade | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 304/ 304L | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 304H | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 40 % |
| 310 / 310S / 310H | 1402 °C (2555 °F) | 7.9 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 40 % |
| 306/ 316H | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 316L | 1399 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 317 | 1400 °C (2550 °F) | 7.9 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 321 | 1457 °C (2650 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 347 | 1454 °C (2650 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 904L | 1350 °C (2460 °F) | 7.95 g/cm3 | Psi 32000 , MPa 220 | Psi 71000 , MPa 490 | 35 % |
Gabriel’s stainless steel manifold valves are precision-machined, hydrostatically tested, and manufactured to comply with global standards, ensuring long-lasting performance, operational safety, and resilience against vibration, pulsation, and aggressive media.
| STANDARD | WERKSTOFF NR. | JIS | UNS | BS | AFNOR | GOST | EN |
| SS 304 | 1.4301 | SUS 304 | S30400 | 304S31 | Z7CN18‐09 | 08Х18Н10 | X5CrNi18-10 |
| SS 304L | 1.4306 / 1.4307 | SUS 304L | S30403 | 3304S11 | Z3CN18‐10 | 03Х18Н11 | X2CrNi18-9 / X2CrNi19-11 |
| SS 304H | 1.4301 | – | S30409 | – | – | – | – |
| SS 310 | 1.4841 | SUS 310 | S31000 | 310S24 | – | 20Ch25N20S2 | X15CrNi25-20 |
| SS 310S | 1.4845 | SUS 310S | S31008 | 310S16 | – | 20Ch23N18 | X8CrNi25-21 |
| SS 310H | – | – | S31009 | – | – | – | – |
| SS 316 | 1.4401 / 1.4436 | SUS 316 | S31600 | 316S31 / 316S33 | Z7CND17‐11‐02 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | SUS 316L | S31603 | 316S11 / 316S13 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 03Ch17N14M3 / 03Ch17N14M2 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SS 316H | 1.4401 | – | S31609 | – | – | – | – |
| SS 316Ti | 1.4571 | SUS 316Ti | S31635 | 320S31 | Z6CNDT17‐123 | 08Ch17N13M2T | X6CrNiMoTi17-12-2 |
| SS 317 | 1.4449 | SUS 317 | S31700 | – | – | – | – |
| SS 317L | 1.4438 | SUS 317L | S31703 | – | – | – | X2CrNiMo18-15-4 |
| SS 321 | 1.4541 | SUS 321 | S32100 | – | – | – | X6CrNiTi18-10 |
| SS 321H | 1.4878 | SUS 321H | S32109 | – | – | – | X12CrNiTi18-9 |
| SS 347 | 1.4550 | SUS 347 | S34700 | – | – | 08Ch18N12B | X6CrNiNb18-10 |
| SS 347H | 1.4961 | SUS 347H | S34709 | – | – | – | X6CrNiNb18-12 |
| SS 904L | 1.4539 | SUS 904L | N08904 | 904S13 | Z2 NCDU 25-20 | STS 317J5L | X1NiCrMoCu25-20-5 |
Gabriel Tube Fittings is a leading supplier and stockist of premium Stainless Steel Manifold Valves in Cairo, Egypt. Our products are extensively used across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our advanced finishing techniques distinguish us in the metal industry. We remain dedicated to consistently providing top-quality manifold valves while effectively meeting the needs of our customers, ensuring reliability and superior performance in every application.
Contact us to get a quick quote for your requirement.
Stainless Steel Manifold Valves are widely used in various industries due to their durability and precise control over fluid flow. In oil and gas industries, they regulate the pressure and flow of liquids and gases. In petrochemical plants, they manage the distribution of corrosive chemicals. These valves are also essential in hydraulic systems, ensuring efficient fluid control. Additionally, they are used in water treatment facilities and power generation plants for high-pressure applications, providing reliable performance under extreme conditions while resisting corrosion and wear.
Please feel free to contact us if you need any further information or for enquiry.
