Stainless Steel Hydraulic Fittings

Home > Stainless Steel > Stainless Steel Hydraulic Fittings

Gabriel Tube Fittings is a reputable manufacturer and supplier located in Cairo, Egypt, specializing in high-quality **Stainless Steel Hydraulic Fittings**. These fittings are crafted to ensure reliable fluid conveyance and connection in high-pressure hydraulic systems. Designed for leak-proof performance, durability, and corrosion resistance, they guarantee consistent operation even in tough industrial settings. Gabriel Tube Fittings follows strict quality standards, delivering hydraulic fittings that comply with international specifications, ensuring a long service life, precise connections, and strong mechanical performance across a variety of applications.

SS Equal Hydraulic Tee Fittings Manufacturer in Cairo, Stainless Steel Hydraulic Equal Elbow Fittings Exporter in Alexandria, Stainless Steel Hydraulic Equal Cross Hydraulic Fittings in Cairo, Egypt, SS Hydraulic Female Stud Coupling Manufacturer in Giza, Stainless Steel Hydraulic Straight Coupling in Port Said, Stainless Steel Hydraulic Tube Fittings Supplier in Cairo, Stainless Steel Hydraulic Male Stud Coupling Price List in Alexandria

Typically, Stainless Steel Hydraulic Fittings are made from materials like SS 304, SS 316, and SS 316L, which include chromium, nickel, and molybdenum. These elements provide outstanding corrosion resistance and mechanical strength. With high tensile strength ranging from 500 to 700 MPa, they also exhibit toughness and resistance to wear and stress from pressure. These fittings are designed for secure connections, minimizing leaks and ensuring dependable performance, even in harsh, high-pressure hydraulic systems.

Stainless Steel Hydraulic Fittings Specifications

DESIGN STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , SS 310, SS 347
MATERIAL
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	(-60C TO 400C)

APPLICATIONS & INDUSTRIES	CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT
MATERIAL DESIGNATOR	STAINLESS STEEL – ASTM A 276 , ASTM 182

Stainless Steel Hydraulic Fittings Chemical Composition

Type	Grade		ASTM A240 Chemical Composition
Type	ASTM(A240M)	Others(JIS)	C	Si	Mn	P	S	Ni	Cr	Mo	Others
Stainless Steels	304	SUS304	≤0.07	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	17.5/19.5	―	N≤0.10
	304H		0.04/0.10	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	18.0/20.0	―
	304L	SUS304L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	8.0/12.0	17.5/19.5	―	N≤0.10
	304N	SUS304N1	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	18.0/20.0	―	N:0.10/0.16
	304LN	SUS304LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	8.0/12.0	18.0/20.0	―	N:0.10/0.16
	309S	SUS309S	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	12.0/15.0	22.0/24.0	―
	310S	SUS310S	≤0.08	≤1.50	≤2.00	≤0.045	≤0.030	19.0/22.0	24.0/26.0	―
	316	SUS316	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N≤0.10
	316L	SUS316L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N≤0.10
	316H		0.04/0.10	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00
	316LN	SUS316LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N:0.10/0.16
	317L	SUS317L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	11.0/15.0	18.0/20.0	3.0/4.0	N≤0.10
	317LN	SUS317LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	11.0/15.0	18.0/20.0	3.0/4.0	N:0.10/0.22
	321	SUS321	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	9.0/12.0	17.0/19.0	―	N≤0.10Ti:5ʷʢC+Nʣ/0.70
	347	SUS347	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	9.0/13.0	17.0/19.0	―	Nb:10ʷC/1.00
	904L	SUS890L	≤0.020	≤1.00	≤2.00	≤0.045	≤0.035	23.0/28.0	19.0/23.0	4.00/5.00	N≤0.10Cu:1.0/2.0
	S31254		≤0.020	≤0.80	≤1.00	≤0.030	≤0.010	17.5/18.5	19.5/20.5	6.0/6.5	N:0.18/0.25Cu:0.50/1.00
		SUS317J2	≤0.06	≤1.50	≤2.00	≤0.045	≤0.030	12.00/16.00	23.00/26.00	0.50/1.20	N:0.25/0.40

Stainless Steel Hydraulic Fittings Mechanical Properties

Type	Mechanical Properties for Stainless Steel Plates
	ASTM(A240M)	Others(JIS)	Tensile Properties			Hardness
	ASTM(A240M)	Others(JIS)	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation (%)	HBW	HRBW
AusteniticSteels	304	SUS304	≥205	≥515	≥40	≤201	≤92
	304H		≥205	≥515	≥40	≤201	≤92
	304L	SUS304L	≥170	≥485	≥40	≤201	≤92
	304N	SUS304N1	≥240	≥550	≥30	≤217	≤95
	304LN	SUS304LN	≥205	≥515	≥40	≤217	≤95
	309S	SUS309S	≥205	≥515	≥40	≤217	≤95
	310S	SUS310S	≥205	≥515	≥40	≤217	≤95
	316	SUS316	≥205	≥515	≥40	≤217	≤95
	316L	SUS316L	≥170	≥485	≥40	≤217	≤95
	316H		≥205	≥515	≥40	≤217	≤95
	316LN	SUS316LN	≥205	≥515	≥40	≤217	≤95
	317L	SUS317L	≥205	≥515	≥40	≤217	≤95
	317LN	SUS317LN	≥240	≥550	≥40	≤217	≤95
	321	SUS321	≥205	≥515	≥40	≤217	≤95
	347	SUS347	≥205	≥515	≥40	≤201	≤92
	N08904/904L	SUS890L	≥220	≥490	≥35	≤196	≤90
	S31254		≥310	≥655	≥35	≤223	≤96
		SUS317J2	≥345	≥690	≥40	≤250	≤100

Top Stainless Steel Hydraulic Fittings Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel Hydraulic Fittings in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel Hydraulic Fittings

SS Hydraulic Straight Coupling in Cairo, Egypt, Hydraulic Stainless Steel Bulkhead Union Price in Cairo, SS Hydraulic Banjo Elbow Supplier in Alexandria, Hydraulic Stainless Steel Swivel Fittings Manufacturer in Giza, SS Hydraulic Male Stud Coupling Price in Port Said, SS Equal Cross Hydraulic Fittings Tube Fittings Supplier And Manufacturer in Cairo

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel Hydraulic Fittings in Cairo, Egypt

You’ll find Stainless Steel Hydraulic Fittings used across various industries, including oil and gas, petrochemical, chemical processing, power generation, and marine applications. They are perfect for hydraulic lines, high-pressure fluid systems, instrumentation setups, and critical machinery where reliability, safety, and precision are paramount. Thanks to their exceptional corrosion resistance, strength, and durability, Stainless Steel Hydraulic Fittings provide efficient and safe operation, making them the go-to choice for demanding hydraulic and industrial applications.

Stainless Steel Hydraulic Fittings Uses

Stainless steel hydraulic fittings are widely used in various industries due to their excellent corrosion resistance and durability. In the oil and gas industry, secure connections are ensured in high-pressure systems, facilitating safe fluid delivery. These fittings effectively manage corrosion in the chemical and petroleum industries, maintaining system integrity. In addition, it is important in food processing and medicine, where hygiene and sanitation are important. Their reliability also makes them suitable for the construction, automotive and aerospace industries, ensuring high-pressure water systems work properly.
