Stainless Steel 316ti Hydraulic Fittings

Home > Stainless Steel > Stainless Steel 316ti Hydraulic Fittings

Gabriel Tube Fittings, based in Cairo, Egypt, specializes in crafting and supplying top-notch **Stainless Steel 316Ti Hydraulic Fittings** that are built to excel in tough and demanding hydraulic systems. These fittings guarantee secure, leak-proof connections that can handle high pressures, mechanical stress, and corrosive environments with ease. Made from titanium-stabilized 316 stainless steel, they offer enhanced resistance to intergranular corrosion and outstanding durability at high temperatures, making them perfect for critical applications in offshore, chemical, and power generation sectors.

SS UNS S31635 Hydraulic Male Stud Coupling in Cairo, Stainless Steel 316ti Equal Cross Hydraulic Fittings Supplier And Manufacturer in Port Said, Hydraulic Stainless Steel DIN 1.4571 Swivel Fittings Manufacturer in Alexandria, SS SUS 316ti Hydraulic Equal Elbow Fittings Manufacturer in Giza, X6CrNiMoTi17-12-2 Stainless Steel Swivel Fittings Supplier in Giza, 316ti SS Equal Cross Hydraulic Fittings Supplier in Cairo

The titanium stabilization in **316Ti stainless steel** effectively prevents carbide precipitation during welding or extended exposure to heat (up to 870°C), ensuring the material retains its strength and corrosion resistance. These fittings boast excellent resistance to pitting, crevice corrosion, and chemical attacks, with a tensile strength of around 550 MPa. Gabriel’s 316Ti hydraulic fittings meet international standards like ISO, SAE, and DIN, and come in a variety of configurations, including adapters, elbows, tees, and reducers, to cater to different hydraulic system needs.

Stainless Steel 316ti Hydraulic Fittings Specifications

DESIGN STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	SS 316TI ( 1.4571)
MATERIAL	SS 316TI ( 1.4571)
SERIES	LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
ACCESSORIES	O-RING, DOWTY SEAL , COPPER WASHER , ED SEAL, CUTTING RING , NUT
O-RING & SEALS	NBR ( -35C TO 100 C ) VITON (-25C TO 200 C) , PTFE – (-60C TO 240)
SURFACE	STAINLESS STEEL 316 TI – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
SURFACE
TEMPERATURE	STAINLESS STEEL – (-60C TO 400C)
MATERIAL DESIGNATOR	STAINLESS STEEL – ASTM A 276 , ASTM 182

Stainless Steel 316ti Hydraulic Fittings Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
SS 316TI	0.08 max	2 max	0.75 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.395 min

Stainless Steel 316ti Hydraulic Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1399 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Stainless Steel 316ti Hydraulic Fittings Equivalent

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316TI	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2

Top Stainless Steel 316ti Hydraulic Fittings Manufacturing Company in Cairo

Engineered for durability and precision, these fittings ensure reliable sealing and straightforward installation, helping to reduce downtime and maintenance costs. When it comes to industries where safety, longevity, and corrosion resistance are crucial, Gabriel’s Stainless Steel 316Ti Hydraulic Fittings are the go-to choice.

Types of Stainless Steel 316ti Hydraulic Fittings

DIN 1.4571 Hydraulic Stainless Steel Bulkhead Union Fittings Price in Giza, Stainless Steel S31635 Hydraulic Banjo Elbow Supplier in Alexandria, Stainless Steel 316ti Hydraulic Female Stud Coupling Manufacturer in Cairo, DIN 1.4571 Stainless Steel Hydraulic Straight Coupling in Port Said, Stainless Steel UNS S31635 Hydraulic Tube Fittings Supplier in Alexandria, 316ti Stainless Steel Hydraulic Straight Coupling in Cairo, Egypt, Stainless Steel SUS 316ti Hydraulic Male Stud Coupling Price List in Cairo, X6CrNiMoTi17-12-2 Stainless Steel Hydraulic Male Stud Coupling Price in Port Said

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 316ti Hydraulic Fittings in Cairo, Egypt

Gabriel Tube Fittings is a leading supplier and stockist of premium Stainless Steel 316ti Hydraulic Fittings in Cairo, Egypt. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 316ti Hydraulic Fittings Uses

Stainless steel 316Ti hydraulic fittings are ideal for applications requiring high corrosion resistance and strength at high temperatures. Widely used in industries such as pharmaceutical, oil gas, petrochemicals, marine environment, where exposure to aggressive chemicals, chlorides and high temperatures is common These fittings also suitable for heat exchangers, boilers and power generation systems, stainless steel 316Ti hydraulic fillers are used in the pharmaceutical and food processing industries, providing long-term serviceability and reliability in water systems.
