Cupro Nickel Hydraulic Fittings

Home > Copper Nickel > Cupro Nickel Hydraulic Fittings

Gabriel Tube Fittings, located in Cairo, Egypt, has made a name for itself as a top-notch manufacturer and supplier of high-quality industrial components, particularly Cupro Nickel Hydraulic Fittings. These fittings are designed with precision and built to last, ensuring reliable performance even in the toughest hydraulic systems, especially those exposed to corrosive and marine conditions. At Gabriel Tube Fittings, they utilize cutting-edge manufacturing techniques and maintain strict quality control to guarantee that every fitting meets international standards. The Cupro Nickel Hydraulic Fittings are crafted for durability, providing leak-free connections and efficient fluid transfer, making them perfect for industries that demand strong, corrosion-resistant hydraulic solutions with exceptional reliability and operational efficiency.

Copper Nickel Hydraulic Female Stud Coupling Manufacturer in Giza, Cupro Nickel Hydraulic Straight Coupling in Port Said, Copper Nickel Hydraulic Tube Fittings Supplier in Cairo, Copper Nickel Hydraulic Male Stud Coupling Price List in Alexandria ,Copper Nickel Equal Hydraulic Tee Fittings Manufacturer in Cairo, Cupro Nickel Hydraulic Equal Elbow Fittings Exporter in Alexandria, Cupro Nickel Hydraulic Equal Cross Hydraulic Fittings in Cairo, Egypt

Gabriel’s Cupro Nickel Hydraulic Fittings are made from top-grade cupro-nickel alloys, which offer outstanding corrosion resistance, high strength, and durability in challenging environments. These fittings boast impressive mechanical properties, including high tensile strength, toughness, and resistance to wear and erosion. With precision-engineered threads and sealing surfaces, they ensure leak-proof connections and easy installation, while their sturdy construction enhances longevity and performance even under high-pressure conditions. Rigorously tested to meet international standards, these fittings are ideal for critical hydraulic applications where mechanical reliability and resistance to aggressive media are crucial for safe and efficient operations.

Copper Nickel Hydraulic Fittings Specifications

DESIGN STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	CUNI 90/10 & CUNI 70/30
MATERIAL	CUNI 90/10 & CUNI 70/30
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	NATURAL FINISH
SURFACE
TEMPERATURE	CUPRO NICKEL – (-60C TO 175C)

Copper Nickel Hydraulic Fittings Chemical Composition

Grade	Cu	Mn	Pb	Ni	Fe	Zn
Cupro Nickel 70/30	65 min	1.0 max	0.05 max	29-33 max	0.4-1.0 max	1 max
Cupro Nickel 90/10	88.6 min	1.0 max	0.05 max	9-11 max	1.8 max	1 max

Copper Nickel Hydraulic Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
0.323 lb/in3 at 68 F	2260 F	50000 psi	20000 psi	30 %
0.323 lb/in3 at 68 F	2260 F	50000 psi	20000 psi	30 %

Copper Nickel Hydraulic Fittings Equivalent

STANDARD	WERKSTOFF NR.	UNS
Cupro Nickel 70/30	2.0882	C71500
Cupro Nickel 90/10	2.0872	C70600

Top Copper Nickel Hydraulic Fittings Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Copper Nickel Hydraulic Fittings in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Copper Nickel Hydraulic Fittings

Cupro Nickel Equal Cross Hydraulic Fittings Tube Fittings Supplier And Manufacturer in Cairo, Hydraulic Copper Nickel Swivel Fittings Manufacturer in Giza, Copper Nickel Hydraulic Male Stud Coupling Price in Port Said, Cupro Nickel Hydraulic Straight Coupling in Cairo, Egypt, Hydraulic Copper Nickel Bulkhead Union Price in Cairo, Cupro Nickel Hydraulic Banjo Elbow Supplier in Alexandria

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Copper Nickel Hydraulic Fittings in Cairo, Egypt

Gabriel Tube Fittings is a leading supplier and stockist of premium Copper Nickel Hydraulic Fittings in Cairo, Egypt. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Copper Nickel Hydraulic Fittings Uses

You’ll find Cupro Nickel Hydraulic Fittings from Gabriel Tube Fittings widely used in marine, offshore, chemical processing, desalination, and industrial hydraulic systems. They create secure, leak-free connections in pipelines, hoses, and hydraulic components, ensuring efficient fluid transfer under high pressure. These fittings are particularly suited for seawater handling, cooling systems, and other corrosive environments where durability and performance are essential. Additionally, they are utilized in laboratories, industrial plants, and offshore platforms, proving their versatility and reliability across various applications.
