Copper Check Valve

Home > Copper > Copper Check Valve

Gabriel Tube Fittings, located in Cairo, Egypt, has built a solid reputation as a manufacturer and supplier of Copper Check Valves. These valves are celebrated for their reliability, durability, and resistance to corrosion. They’re specifically designed to allow fluid to flow in one direction while preventing backflow, making them perfect for plumbing, HVAC, and refrigeration systems. Gabriel Tube Fittings takes pride in ensuring that each valve is meticulously engineered and rigorously tested to meet international quality standards. Their Copper Check Valves are appreciated for their smooth operation, straightforward installation, and long lifespan, making them a great fit for residential, commercial, and industrial fluid control needs.

Copper Check Valve Manufacturer in Cairo, Copper Swing Check Valve Exporter in Alexandria, Copper Inline Check Valve Supplier in Giza, Copper Check Valve Supplier in Port Said, Copper Sanitary Check Valve In Giza, Copper Piston Check Valve In Port Said, Copper Socket Weld Check Valves Price List in Cairo, Copper Swing Check Valves Manufacturer in Cairo, Copper Poppet Check Valve in Alexandria, Egypt

These Copper Check Valves are crafted from high-quality copper or copper alloys, which provide excellent thermal and electrical conductivity, along with impressive resistance to corrosion and biofouling. The material boasts moderate tensile strength, typically ranging from 210 to 350 MPa, and offers good ductility and pressure-handling capabilities. Thanks to copper’s natural antimicrobial properties, along with its superior heat transfer and corrosion resistance, these valves are particularly effective in water and air systems that are exposed to moisture and fluctuating temperatures.

Copper Check Valve Specifications

BRAND NAME	Gabriel Tube Fittings
COPPER VALVES SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
CONNECTION	THREADED, TUBE END, SOCKET WELD END, FLANGE END
COPPER VALVES THREADS	NPT, BSPP, BSPT, METRIC, JIC, UNF
FLOW PATTERN	STRAIGHT
COPPER VALVES BODY SHAPE	HEXAGON
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI
CRACKING PRESSURE	0.5 BAR
COPPER VALVES ORIFICE SIZE	2 MM TO 40 MM
COPPER VALVES TYPE	POPPET TYPE, SPRING TYPE
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
COPPER VALVES MEDIA TEMPERATURE	(-50* C TO 350*C ) RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK, FORGED
PACKING DETAILS	WOODEN PALLET, BOX PACKING
COPPER VALVES EQUIVALENT BRANDS	SWAGELOK, PARKER, STAUFF, DK-LOK, HAMLET, OLIVER VALVES, HOKE
MATERIAL	COPPER, CUPRO NICKEL, CUNI 90/10, CUNI 70/30

Copper Check Valve Chemical Composition

Grade	Zn	Mn	Cu	Ni	Pb	Fe
Cu-Ni 70-30	1 max	1 max	65.0 min	29-33	.05 max	0.4-1.0
Cu-Ni 90-10	1 max	1.0 max	88.6 min	9-11 max	.05 max	1.8 max

Copper Check Valve Mechanical Properties

	Cu-Ni 90/10		Cu-Ni 70/30
Properties	Imperial	Metric	Imperial	Metric
yield Tensile strength,	16000-57000 psi	110-393 MPa	12800-70100 psi	88.0-483 MPa
ultimate, Tensile strength	43900-60000 psi	303-414 MPa	54000-75000 psi	372-517 MPa
Machinability	20%	20%	20%	20%
at break Elongation	42.00%	42.00%	45.0%	45.0%
ratio Poisson’s	0.34	0.34	0.34	0.34
modulus Shear	7540 ksi	52.0 GPa	8270 ksi	57.0 GPa
modulus Elastic	20300 ksi	140 GPa	21800 ksi	150 GPa

Top Copper Check Valve Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the leading supplier, manufacturer, and exporter of Copper Check Valves in Cairo, Egypt. Our advanced manufacturing facilities, strategically located in the Egypt, allow us to deliver high-quality, customized solutions tailored to your specific needs. With a comprehensive inventory of premium-grade copper materials, we are fully equipped to meet your demands efficiently. Our commitment to excellence and operational efficiency ensures that we consistently maintain sufficient stock to support your business requirements effectively.

Types of Copper Check Valve

Copper Check Valve, Copper Swing Check Valve in Giza, Copper Sanitary Check Valve Price in Cairo, Copper Socket Weld Check Valves Supplier in Alexandria, Copper Piston Check Valve Manufacturer in Giza, Copper Poppet Check Valve Price in Port Said, Copper Swing Check Valves Supplier and Manufacturer in Cairo, Copper Inline Check Valve in Cairo, Egypt.

Copper Check Valve Equivalent Grade

COPPER VALVES STANDARD	WNR.	UNS
Copper Nickel 90/10	2.0872	C70600
Copper Nickel 70/30	2.0882	C71500

Largest Manufacturer and Supplier of Copper Check Valve in Cairo, Egypt

You’ll find Copper Check Valves commonly used in plumbing systems, heating and cooling setups, refrigeration units, and water distribution lines. They play a crucial role in preventing reverse fluid flow, which protects pumps, compressors, and pipelines from potential damage. Given copper’s resistance to corrosion and its hygienic qualities, these valves are also a top choice for potable water systems. Their durability, low maintenance needs, and efficient performance make them a trustworthy option for a wide array of domestic and industrial applications.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Copper Check Valve Uses

Copper Check Valves are widely used in plumbing, heating, and HVAC systems to prevent backflow and ensure the efficient flow of liquids. Their corrosion resistance makes them ideal for hot and cold water supply lines, as well as for drainage applications. These valves are also utilized in refrigeration systems, gas pipelines, and chemical processing plants, where they help maintain system integrity by preventing reverse flow. Additionally, their lightweight nature facilitates easy installation, while their durability ensures long-lasting performance in various industrial and residential settings.
