Stainless Steel Condensate Pots

Home > Stainless Steel > Stainless Steel Condensate Pots

Gabriel Tube Fittings is a reputable manufacturer and supplier located in Cairo, Egypt, specializing in high-quality **Stainless Steel Condensate Pots**. These pots are expertly designed to safeguard instrumentation systems and ensure precise measurements in various industrial settings. They effectively separate condensate from steam or gas, which helps prevent damage to pressure gauges, transmitters, and other delicate instruments. With a commitment to precision and compliance with international standards, Gabriel Tube Fittings delivers durable, corrosion-resistant products that are perfect for high-pressure and high-temperature environments.

Stainless Steel Type D Condensate Pot with Red Oxide Coated Manufacturer Cairo, Stainless Steel Type E Condensate Pot with Zinc Plating Dealer Alexandria, SS Type F Condensate Pots Supplier Giza, 316 Stainless Steel Type D Condensate Pot Exporter In Port Said, Stainless Steel Type E Condensate Pot with Galvanized Plating Sockets Manufacturer Cairo, Stainless Steel Type F Condensate Pots with 6 Ports Supplier Cairo, Egypt.

Typically crafted from materials like SS 304, SS 316, and SS 316L, these Stainless Steel Condensate Pots are infused with chromium, nickel, and molybdenum to boost their corrosion resistance and mechanical strength. They boast impressive tensile strength, usually ranging from 500 to 700 MPa, along with excellent toughness and resistance to pitting, crevice corrosion, and general wear. Their sturdy construction guarantees reliable performance, even in challenging process conditions, ensuring a long service life with minimal maintenance.

Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Top Stainless Steel Condensate Pots Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel Condensate Pots in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel Condensate Pots

Sizing Of Stainless Steel Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

SS Type D Condensate Pots Price in Cairo, SS Type E Condensate Pots Manufacturer Supplier in Alexandria, Stainless Steel Type F Condensate Pot with Red Oxide Coated Manufacturer in Giza, Stainless Steel 316 Socket Weld Half Couplings Price in Port Said, Stainless Steel Type D Condensate Pot with Galvanized Plating Supplier And Manufacturer in Cairo, Stainless Steel Type E Condensate Pots with 4 Ports Dealer In Giza, Stainless Steel Type F Condensate Pot with Galvanized Plating In Cairo, Egypt.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Stainless Steel Condensate Pots Supplier in Cairo, Egypt

These Stainless Steel Condensate Pots find extensive use across various industries, including oil and gas, petrochemical, chemical processing, power generation, and marine applications. They play a crucial role in steam systems, pipelines, and process instrumentation lines, protecting equipment from high-temperature fluids and corrosive substances. Thanks to their durability, corrosion resistance, and meticulous engineering, Stainless Steel Condensate Pots are the go-to choice for maintaining safe, efficient, and reliable operations in industrial measurement and control systems.

Stainless Steel Condensate Pots Uses

Stainless steel condensate pots are primarily used to collect and remove condensate from steam, gas, and fluid lines in industrial systems, ensuring accurate pressure readings and preventing damage to instrumentation. They are widely used in power plants, oil and gas pipelines, chemical processing, and refineries to maintain the efficiency of measurement devices. Additionally, these pots help prevent corrosive damage to equipment by trapping condensate, protecting sensitive instruments from high temperatures and pressures. Their durability and corrosion resistance make them ideal for harsh industrial environments.
