Gabriel Tube Fittings, based in Cairo, Egypt, is a leading manufacturer and supplier of high-quality tube fittings for various industrial applications. Committed to excellence, the company provides products that meet strict industry standards. Among its offerings are Inconel 625 Tube Fittings, known for their outstanding strength, corrosion resistance, and durability. These fittings are ideal for critical applications in industries such as chemical processing, aerospace, and marine, ensuring reliable performance in extreme environments. Gabriel Tube Fittings delivers solutions tailored to the toughest demands.
**Gabriel Tube Fittings**, based in Cairo, Egypt, is a reputable manufacturer and supplier of high-performance **Inconel 625 Tube Fittings** designed for tough applications that face extreme temperatures, high pressures, and corrosive environments. These tube fittings guarantee leak-proof, vibration-resistant connections in critical fluid and gas systems.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6010 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application | |
| Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Inconel 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Gabriel’s **Inconel 625 Tube Fittings** come in a variety of configurations—**unions, elbows, tees, adapters, reducers**, and more—compatible with double-ferrule or compression-style connections. These fittings are precision-machined to tight tolerances, ensuring reliable sealing, easy installation, and minimal maintenance under varying thermal and mechanical loads.
Contact us to get a quick quote for your requirement.
Inconel 625 Tube Fittings are used in applications where resistance to high temperatures, corrosion and oxidation is very important. Because they can withstand extreme temperatures they are ideal for aerospace components such as jet engines, exhaust systems and turbine seals In marine engineering these components provide excellent protection against seawater corrosion, and making them for offshore platforms and underwater equipment In addition to being suitable, they are widely used in chemical plants to prevent corrosion by acid gases, providing durability and reliability if operating in areas severe
Please feel free to contact us if you need any further information or for enquiry.
