Duplex BSP / NPT Fittings

Home > Duplex > Duplex BSP / NPT Fittings

Gabriel Tube Fittings, a reputable manufacturer and supplier located in Cairo, Egypt, focuses on delivering top-notch Duplex BSP / NPT Fittings that adhere to international industrial standards. These fittings are made from high-quality duplex stainless steel, which provides remarkable strength, durability, and resistance to corrosion. With state-of-the-art production facilities and rigorous quality control, Gabriel Tube Fittings guarantees precise dimensions and leak-free performance. Their Duplex BSP / NPT Fittings are perfect for challenging environments, ensuring dependable connections in fluid and gas handling systems across various industries in Egypt and beyond.

DSS S31803 BSP Threaded Elbow Manufacturer Cairo, SAF 2205 BSP / NPT Tee Dealer Alexandria, Duplex Stainless Steel S32205 Cap NPT Thread Supplier Giza, ASTM A182 DSS 2205 NPT Threaded Pipe Cap Exporter In Port Said, ASTM A182 DSS F60 NPT Cap Manufacturer Cairo, Duplex Steel F51 NPT Screwed Tee Cairo, Egypt.

The Duplex BSP / NPT Fittings are crafted from a well-balanced blend of austenitic and ferritic stainless steels, featuring chromium (around 22–25%), nickel (5–7%), and molybdenum (3–4%). This unique composition offers outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. On the mechanical side, these fittings boast high tensile strength, impressive hardness, and excellent fatigue resistance, making them ideal for high-pressure and high-temperature applications. They also retain great weldability and toughness, even in sub-zero conditions.

Duplex BSP / NPT Fittings Specifications

Specifications: ASTM A182/ ASME SA182
Size: 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Types : Socketweld Fittings, Screwed-Threaded Fittings
Pressure Rating: Threaded End-2000lb/ 3000lb/ 6000lbs / Socket-weld End-3000/ 6000/ 9000lbs
Thread: NPT, BSPT, BSPP

Duplex BSP / NPT Fittings Chemical Composition

MATERIAL	C	MN	SI	P	S	CR	MO	NI	N	FE
Duplex BSP / NPT Fittings	.030 Max	2.00 Max	1.00 Max	.030 Max	.020 Max	22.0-23.0	3.00-3.50	4.50-6.50	0.14-0.20	Balance

Duplex BSP / NPT Fittings Mechanical Properties

DENSITY	MELTING POINT	TENSILE STRESS	YIELD STRESS (0.2%OFFSET)	ELONGATION
7.8 g/cm3	1350 °C (2460 °F)	Psi – 116000 , MPa – 800	Psi – 80000 , MPa – 550	15 %

Types of Duplex BSP / NPT Fittings

Equivalent Grades of Duplex BSP / NPT Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy BSP C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760
Hastelloy NPT C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–

S31803 Duplex NPT Threaded Plug Price in Cairo, ANSI B16.11 Duplex S31803 NPT x BSP Cross Manufacturer Supplier in Alexandria, ASTM A182 Duplex Steel S32205 NPT Threaded Cross Manufacturer in Giza, DSS F51 BSP Equal Crosses Manufacturer & Price in Port Said, Duplex Steel F51 BSP Thread Union Supplier And Manufacturer in Cairo, F54 DSS MSS SP-83 NPT Thread Union In Cairo, Egypt.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Duplex BSP / NPT Fittings in Cairo, Egypt

At Gabriel Tube Fittings, We are proud to be the largest supplier, manufacturer, and exporter of Duplex BSP / NPT Fittings in Cairo, Egypt. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Egypt, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Duplex BSP / NPT Fittings Uses

These fittings find extensive use in numerous industrial sectors, including chemical processing, marine, oil and gas, desalination plants, and power generation. Their remarkable corrosion resistance and strength make them suitable for pipelines, instrumentation systems, and high-pressure hydraulic lines. These fittings ensure secure, leak-proof connections in fluid and gas systems, even under extreme operating conditions. Plus, their versatility and long lifespan make them a go-to choice for offshore platforms, heat exchangers, and other applications that demand durability and efficiency in corrosive environments.
