Gabriel Tube Fittings, located in Cairo, Egypt, stands out as a top manufacturer and supplier of precision-engineered industrial components, including swivel pipe adaptors. Known for their quality, durability, and precision, Gabriel’s swivel pipe adaptors are crafted to ensure secure, leak-proof, and flexible connections in piping and hydraulic systems. Each adaptor is built to meet international quality standards, guaranteeing smooth performance, easy installation, and a long service life. Catering to both local and international markets, Gabriel Tube Fittings offers reliable and efficient connection solutions tailored to the demands of modern industrial applications.
These swivel pipe adaptors are typically constructed from corrosion-resistant materials like stainless steel, carbon steel, or brass, providing excellent mechanical strength and durability. They feature a swivel nut design that allows for 360-degree rotation, simplifying installation and alignment without putting stress on the piping system. Their mechanical properties include high tensile strength, vibration resistance, and superior sealing performance, ensuring long-term reliability even in high-pressure and high-temperature environments.
|
Mcneil Instruments PART # |
END SIZE |
C2 HEX BODY (in.) |
W4 (in.) |
Dynamic Pressure (x 1,000 PSI) |
||||
|
1 UN/UNF-2A |
2 NPSM |
|||||||
|
-S |
-SS |
-B |
||||||
| 0507-4-2 |
7/16 – 20 |
1/8 – 27 |
9/16 |
1.21 |
6.0 |
6.0 |
3.3 |
|
| 0507-4-4 |
7/16 – 20 |
1/4 – 18 |
9/16 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-5-4 |
1/2 – 20 |
1/4 – 18 |
5/8 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-4 |
9/16 – 18 |
1/4 – 18 |
11/16 |
1.35 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-6 |
9/16 – 18 |
3/8 – 18 |
11/16 |
1.37 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-8 |
9/16 – 18 |
1/2 – 14 |
3/4 |
1.57 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-4 |
3/4 – 16 |
1/4 – 18 |
7/8 |
1.43 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-6 |
3/4 – 16 |
3/8 – 18 |
7/8 |
1.45 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-8 |
3/4 – 16 |
1/2 – 14 |
7/8 |
1.56 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-12 |
3/4 – 16 |
3/4 – 14 |
1 |
1.79 |
4.0 |
4.0 |
2.6 |
|
| 0507-10-6 |
7/8 – 14 |
3/8 – 18 |
1 |
1.59 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-8 |
7/8 – 14 |
1/2 – 14 |
1 |
1.73 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-12 |
7/8 – 14 |
3/4 – 14 |
1 1/4 |
1.88 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-8 |
1 1/16 – 12 |
1/2 – 14 |
1 1/4 |
1.88 |
5.0 |
5.0 |
3.3 |
|
| 0507-12-12 |
1 1/16 – 12 |
3/4 – 14 |
1 1/4 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-16 |
1 1/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-14-12 |
1 3/16 – 12 |
3/4 – 14 |
1 3/8 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-12 |
1 5/16 – 12 |
3/4 – 14 |
1 1/2 |
1.90 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-16 |
1 5/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-16 |
1 5/8 – 12 |
1 – 11 1/2 |
1 7/8 |
2.20 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-20 |
1 5/8 – 12 |
1 1/4 – 11 1/2 |
1 7/8 |
2.21 |
2.5 |
2.5 |
1.6 |
|
| 0507-24-24 |
1 7/8 – 12 |
1 1/2 – 11 1/2 |
2 1/8 |
2.39 |
2.0 |
2.0 |
1.3 |
|
| 0507-32-32 |
2 1/2 – 12 |
2 – 11 1/2 |
2 3/4 |
2.49 |
1.5 |
1.5 |
1.0 |
|
At Gabriel Tube Fittings, we are the leading supplier, manufacturer, and exporter of Swivel Pipe Adaptor in Cairo, Egypt. Our state-of-the-art manufacturing facilities, strategically located in the Egypt, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Swivel pipe adaptors find extensive use in industries such as oil and gas, chemical processing, hydraulic systems, and instrumentation. They are perfect for applications that require flexibility and ease of assembly, especially in systems with dynamic movement or limited space. Their design not only helps reduce installation time but also prevents leaks and enhances overall system performance. With their sturdy construction, corrosion resistance, and adaptability, swivel pipe adaptors from Gabriel Tube Fittings deliver efficient, durable, and maintenance-free performance across a wide array of industrial applications.
Contact us to get a quick quote for your requirement.
Swivel pipe adaptors are versatile components widely used in various applications. They are primarily employed in plumbing systems to connect pipes at different angles without causing stress or leaks. In hydraulic systems, these adaptors facilitate fluid transfer, allowing for smooth movement and rotation, which is essential for machinery and equipment. They are also commonly used in irrigation systems to connect hoses and fittings, ensuring efficient water distribution. Additionally, swivel pipe adaptors are utilized in automotive and industrial applications, providing flexibility and durability for safe and effective fluid handling.
Please feel free to contact us if you need any further information or for enquiry.
